ANNK H.265+ 5MP Lite Ultra HD 8CH DVR CCTV Security System 8PCS Outdoor 5MP EXIR Night Vision Camera Video Surveillance Kit
5MP CMOS Camera Key Features:
1.Stunning 5MP Super HD Resolution
2.Cutting-Edge H.265+ Video Compression
3.Superb Night Vision with EXIR Array LEDs
4.USB 3.0 Backup Video Output
5.Email Alarm with Snapshots and APP Push
6.Easy Remote Access on Mobile Devices
7.IP67 Weatherproof Cameras
8.Smart Search/Playback Function
9.Multiple Languages Supported
10.Plastic Housing
3K CMOS Camera Key Features (White Color):
High quality imaging with 3K, 2960 × 1665 resolution
2.8 mm fixed focal lens@F1.2
High quality audio with audio over coaxial cable, built-in mic
Up to 25 m IR distance for bright night imaging
Up to 20 m white light distance for bright night imaging
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP67)
What's Included?
* 1× 8CH DVR
* 4/8× 5MP Camera
* 1/2× 5.9ft/1.8m HDMI Cable
* 1/2× 3.2ft/1m Ethernet Cable
* 1× Power Adapter for DVR
* 1× Power Adapter for Cameras
* 4/8× 60ft/18.3m BNC Cable
* 1× USB Mouse
* 1× User Manual & Software CD
* 4/8× Mounting Screw Kit
* No HDD or 1T /2T/3T/4T HDD for your option
This security system provides 5MP recording and live viewing with a higher resolution (2560×1944). It can be installed at the front door to capture clear human faces and plate numbers, can also be mounted in high positions for rich details of far-away objects.
Ultra-Long Recording Time with H.265 + Coding
The latest H.265+ compression provides smooth and instant streaming, reduces video file sizes to save valuable hard drive space. With the pre-installed 1 TB hard driver disk, the surveillance system can record 24/7, and records 98 days without overwriting.
Easy Remote Access
By downloading thefree ANNKE Vision App, you can stream live viewing and playback video records via your smart phone and tablet. You can always know what's going on in your house or shop, even if you are a thousand miles away.
Effective 100 ft Night Vision
2 infrared LEDs and advanced IR technology enable an excellent night vision, letting you see any event clearly even in the dark. With a long night vision distance up to 100 feet, you can accurately identify human present in the event captured by this security camera.
Smart Search/Playback Function
The smart search/playback feature enables you to locate and check the video clips with motion events quickly and accurately. You can skip the non-related videos or play them at a higher speed. The smartplayback rules and areas are configurable.
IP67 Waterproof Cameras Built for Any Climate
This outdoor security camera can protect you in all types of weather throughout all seasons.Rain, hail, storm, snow, sleet and sunshine, this camera always performs well; it also withstands extreme temperature from -40 °F to 140 °F.
Information Security Measures
Our products adopt information protection technology of military grade, and protect your data safety firmly. You can set password and encryption code for access restrictions, avoiding hacker attacks and privacy leaks.
DVR | ||
Video & Audio | Video Compression | H.264+/H.264/H.265/H.265+ |
Video Input | 8CH Analog HD/Analog + 2CH IP Video (up to 12 channel when IP enhanced mode on) | |
Video Output | HDMI and VGA Up to 1080P | |
Audio Input | 1-ch RCA,8-ch via coaxial cable | |
Audio Output | 1-ch RCA | |
Supported Camera Types | Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p; | |
Analog HD Playback Resolution | 3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps | |
IPC Playback Resolution | Up to 6MP | |
Max Playback Channel | 2-ch | |
Protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS | |
Motion Detection 2.0 | All analog channels support human and vehicle detection to reduce false alarm | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 10TB capacity | |
External Interface | Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
USB | USB2.0x2 | |
General | Operating Power | DC12V,≤ 12W (without HDD) |
Working Temperature | -14 °F – 131 °F /-10 °C – 55 °C | |
Dimensions(W x H x D) | 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) | |
Weight (without hard disk) | ≤ 1 kg (2.2 lb)(without HDD) | |
5MP CMOS Camera | ||
Image sensor | 5MP CMOS Image sensor | |
Camera | Video Resolution | 2560 (H) × 1944 (V) |
Signal System | PAL/NTSC | |
Frame Rate | PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps | |
Lens | 2.8mm | |
Min.Illumination | Color:0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
Angle of View | 85.5° | |
Number of Infra-Red LEDs | 2 | |
Night Vision Distance | Up to 100ft/30m | |
DNR | 2D DNR | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | Yes | |
Video Output | HD BNC×1 | |
General | Housing | Plastic |
Color | White | |
Operating Power | DC12V | |
Operating Temperature | -40 °F – 140 °F /-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP67 | |
Dimension (L x W x H) | 2.28' x 2.40' x 6.42' / 58 x 61 x 163mm | |
Weight | 0.4lbs / Approx. 180g | |
3K CMOS Camera(White Color) | ||
Camera | Image sensor | 3K CMOS Image sensor |
Video Resolution | 2960 (H) × 1665 (V)(16:9) | |
Signal System | PAL/NTSC | |
Frame Rate | TVI: 3K@20 fps, 4 MP@25 fps/30 fps, 1080p@25 fps/30 fps | |
Lens | 2.8mm | |
Min.Illumination | Color:0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
Angle of View | Horizontal FOV: 107°, vertical FOV: 64°, diagonal FOV: 129° | |
Supplement Light type | 1 white Light & 2 EXIR | |
Supplement Light Range | IR : Up to 25 m, white Light : Up to 20 m | |
Supplement Light Mode | IR light works normally, and it switches to white light when human or vehicle are detected at night. | |
Wide Dynamic Range | Digital WDR | |
Audio | Built-in mic | |
IR Cut Filter | Yes | |
Video Output | BNC, switchable TVI/AHD/CVI/CVBS | |
General | Housing | Plastic |
Color | Black | |
Operating Power | 12 VDC ± 25% | |
Consumption | Max. 2.9 W | |
Operating Temperature | -40 °F – 140 °F /-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP67 | |
Dimension (L x W x H) | 138.8 mm × 60.9 mm × 57.9 mm (5.47" × 2.4 " × 2.3") | |
Weight | Approx. 155 g (0.34 lb.) | |
8CH+4PCS CCTV Kit Include:
8CH+8PCS CCTV Kit Include:
