ANNKE 12MP 3K Outdoor Smart Dual Light PoE Security Camera Color IR Night Vision Built-in Microphone IP67 Smart Home H.265+
★ 12MP/3K Smart Dual-Light Network Camera
★ Motion detection 2.0 with people and vehicle detection
★ Efficient H.265+ compression technology
★ 2.8mm@F1.6 lens brings everything back to life
★ Built-in microphone for real-time audio security
★ Support up to 512GB SD card storage
★ Clear imaging even with strong back lighting due to 120 dB WDR
★ IP67 Dust and Waterproof Rating
★ Support PoE (Power over Ethernet)&DC12V
ANNKE 12MP image quality, output 4096*3072 screen
1/2.7" Progressive Scan BSI CMOS IMAGE SENSOR, output 4096*3072 high-definition image quality, clear vision.
12MP Visual Experience: More Detailed Images
Cutting-edge 12MP security camera, delivering unrivaled clarity with a staggering 4096 x 3072 resolution. See every detail in vivid precision, ensuring nothing escapes your watchful eye. The 2.8mm@F1.6 lens guarantees impeccable low-light performance, capturing crisp, well-defined images even in challenging conditions.
Smart dual light:
By default, the infrared light is on at night and the picture is black and white.
When a person or vehicle is triggered, the infrared light goes out and the white light turns on to turn into a color picture. The color picture is better than the black and white picture.
Three modes to choose from: infrared and white light fill light up to 30 meters.Elevate Security Precision: Deep Learning Algorithms
With Motion Detection 2.0, rest assured that you'll only receive alerts for relevant activity – eliminating 99% of unwanted notifications caused by animals, weather elements, or non-essential objects. Our system intelligently focuses on human and vehicle shapes by default, drastically reducing false alarms.Built-in high-sensitivity pickup, supports environmental noise filtering, and can also record during video recording
[Smart Search & Playback]
This smart PoE camer makes it easier for you to find what you want in loads of videos and helps you to locate the vital clips in a sec. What's more, you can access&control the C1200 camera to perform remote access via the ANNKE APP.[Memory Card & NVR Storage Allowed]
The camera not only supports up to 512GB microSD card(not included) to store but NVR recording. ANNKE NVR works best with this 12MP PoE camera, which can let you enjoy crystal-clear image quality without distortion, extra-long recording and use less bandwidth.
3K/5MP IP Camera | ||
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 2.8 mm | |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° | |
Supplement Light Type | Smart Dual-Light, IR, White Light | |
Supplement Light Range | Up to 30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | |
API | Open Network Video Interface Version 18.12 | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White & Black | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 512 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67 | |
Dimension (L X W X H) | 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") | |
Weight | 0.6 lb./270 g | |
12MP IP Camera | ||
Camera | Image Sensor | 1/2.7" Progressive Scan CMOS |
Max resolution | 4096*3072(12MP) | |
Main Stream | 50 Hz: 10 fps@4096*3072, 12.5 fps@(3840*2160, 3200*1800, 2688*1520, 1920*1080, 1280*720) | |
Substream | 50 Hz: 12.5 fps (1280*720, 640*480, 640*360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 16 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 2.8 mm | |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 113°, vertical FOV 62°, diagonal FOV 134° | |
Supplement Light Type | Smart Dual-Light, IR, White Light | |
Supplement Light Range | Up to 30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP | |
API | Open Network Video Interface Version 19.12 (Profile S, Profile T, Profile G) | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Rotate mode, mirror, password protection, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White & Black | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 512 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67 | |
Dimension (L X W X H) | 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") | |
Weight | 0.6 lb./285 g | |
