State-Of-The-Art H.265+ Codec
Normally, the H.265+ coding standard enables fast transmission and stable steam, records up to 98 days continuously for 4 cameras simultaneously with 1TB HDD, which is 7 times longer than H.264, saving plenty of money from buying extra hard disk drive
Up to 5MP Ultra HD Input
The DVR supports 5MP cameras to provide you 5MP streaming and 5MP lite recording, bring everything to life with stunning and clear details, even the license plate and human face can be recognized easily
Compatible 5-in-1 DVR
This powerful DVR supports up to 8CH TVI/AHD/CVI/CVBS and 2 IP cameras, thus you make full use of all your old cameras or brand new cameras for wide coverage. Clear off blind spot and leave nowhere for thieves and robbers to hide
Smart Motion-Triggered Alerts
Mark out relevant areas for motion detection, you can focus on what you care most and free from irrelevant alerts. Once alarm is triggered, it will send instant email alerts with snapshots and APP alarm pushes, so you can take appropriate precautions
Easy 3-Step Remote Access
Consolidating the security system into your smartphone, tablet and PC can be quite simple with our free Annke Vision APP. Quick scan the QR-code, install it on your mobile devices and then you can watch live video anytime from anywhere.
Multi-language Operation
Both DVR menu and APP support multi-language operation, no worry about maloperation caused by difficulties in languages. It is much more convenient to keep your home and business safe via surveillance system with your familiar language.
Save Time with Smart Playback
The smart playback offers you video with movements in selected areas and period. Thus you don't have to waste time on checking footage frame by frame. It is much easier to find what you need in the records.
![]()
Information Security Measures
Adopted information protection technology of military grade, your date is on our top priority and well-protected. Therefore, you could set password and encryption code for access restrictions, avoiding access open to everyone like other brands.
![]()
1080P Full HD HDMI & VGA Output
The DVR supports HDMI and VGA 1080P full-HD outputs, so you can connect a HD monitor to it for live viewing and video playback. Default HDMI/VGA output resolution is 1024*768, please adjust it manually for higher resolution.
![]()
DVR Specification:
NO RS485
Video Compression :H.264+/H.264/H.265/H.265+
Video Input :16CH Analog HD/Analog+2CH IP (up to 18-ch)
Enhanced IP mode on:8-ch (up to 24-ch), each up to 4 Mbps
Video Output :HDMI and VGA Up to 1080P
Audio Input/Output :1-ch RCA, 16-ch via coaxial cable
Analog HD Playback Resolution :5MP Lite/4MP Lite@12fps,1080p/720p@15fps
IPC Playback Resolution :Up to 6MP
Max Playback Channel: 4-ch
Onvif Protocols :Support
HDD :1 SATA interface
Motion Detection 2.0: All analog channels support human and vehicle detection to reduce false alarm
HDD Capacity :Up to 6TB capacity
Network interface :RJ45x1(10/100M)
USB :USB2.0x2
Operating Power: DC12V
Working Temperature :-14 °F – 131 °F /-10 °C – 55 °C
Dimensions(W x H x D) :260 × 222 × 45 mm
Weight (without hard disk) :≤ 1 kg (2.2 lb)(without HDD)
![]()
Packaging Contents:
x1 DVR
x1 USB Mouse
x1 Power Adapter
x1 HDMI Cable
x1 Network Cable
x1 User's Manual For DVR
![]()
