ANNKE 8CH Video Surveillance Kit 5in1 DVR Protection Security Camera H.265+ Weatherproof IP67 CCTV Camera System Remote Monitor
DVR:
· Up to 3K high definition live viewing
· Up to 3K Lite recording & playback
· Advanced H.265 Pro+ Video Compression
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhone, iPad, Android mobile remote monitoring
· Deep learning based human and vehicle targets classification of Motion Detection 2.0 for all analog channels
· Quick search by object or event type
· Audio via coaxial cable
Camera:
· High quality imaging with 3K, 2960 × 1665 resolution
· 2.8 mm fixed focal lens@F1.2
· High quality audio with audio over coaxial cable, built-in mic
· Up to 30m IR distance for bright night imaging
· Up to 20 m white light distance for bright night imaging
· One port for four switchable signals (TVI/AHD/CVI/CVBS)
· Water and dust resistant (IP67)
[5-in-1 Hybrid DVR with 2 Switchable Modes]
Featuring the DVR/NVR/HVR tech, this expandable hybrid 5MP DVR supports up to 8 pcs 5MP TVI, 4MP AHD & CVI, CVBS analogs & extra 2 pcs 6MP IP cameras. 10 pcs IP cameras work together once switch to IP signal. [ONLY WORKS WITH ANNKE IP CAMERAS]
[3 Event Analytics & AI motion detection]
3 intelligent modes can be chosen, including motion detection, line crossing detection, and intrusion detection. Once click the AI Human/Vehicle Detection as a filter, you'll be aware of real threats as app pushes & email alerts are sent instantly and be truly free from unnecessary alerts!
[Remote Access & Smart Search]
Access the DVR at any time anywhere via 3G/4G/5G or WiFi with your smartphones, tablets, computers, and browsers (Google Chrome, Firefox, Microsoft Edge, Internet Explorer, Safari, etc.). Tired of the searching? You can use Smart Search to find human & vehicle motion events in only a few seconds!
[Exclusive H.265+ Coding & Automatic Overwrite]
Unlike H.264, H.265+ saves up to 80% storage space while keeping vivid image quality! Automatic overwrite tech refreshes the storage to ensure a continuous recording when the space is full! Say bye to the straining bandwidth from now on!
0TB:
1TB:
2TB:
4TB:
DVR:
Video & Audio | Video Compression | H.264+/H.264/H.265/H.265 Pro+ |
Video Input | 8CH Analog HD/Analog + 2CH IP Video (up to 12 channel when IP enhanced mode on) | |
Video Output | HDMI and VGA Up to 1080P | |
Audio Input | 1-ch RCA,8-ch via coaxial cable | |
Audio Output | 1-ch RCA | |
Supported Camera Types | Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p; | |
Analog HD Playback Resolution | 3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps | |
IPC Playback Resolution | Up to 6MP | |
Max Playback Channel | 8-ch | |
Network Protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS | |
Total Bandwidth | 96Mbps | |
Remote Connection | 64 | |
Motion Detection 2.0 | All analog channels support human and vehicle detection to reduce false alarm | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 10TB capacity | |
External Interface | Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
USB | USB2.0x2 | |
General | Operating Power | DC12V,≤ 12W (without HDD) |
Working Temperature | -14 °F – 131 °F /-10 °C – 55 °C | |
Dimensions(W x H x D) | 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) | |
Weight (without hard disk) | ≤ 1 kg (2.2 lb)(without HDD) |
Camera:
Camera | Image sensor | 3K CMOS Image sensor |
Video Resolution | 2960 (H) × 1665 (V)(16:9) | |
Signal System | PAL/NTSC | |
Frame Rate | TVI: 3K@20 fps, 4 MP@25 fps/30 fps, 1080p@25 fps/30 fps | |
Lens | 2.8mm | |
Min.Illumination | Color:0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
Angle of View | Horizontal FOV: 107°, vertical FOV: 64°, diagonal FOV: 129° | |
Supplement Light type | 1 white Light & 1 EXIR | |
Supplement Light Range | IR : Up to 30 m, white Light : Up to 20 m | |
Supplement Light Mode | IR light works normally, and it switches to white light when human or vehicle are detected at night. | |
Wide Dynamic Range | Digital WDR | |
Audio | Built-in mic | |
IR Cut Filter | Yes | |
Video Output | BNC, switchable TVI/AHD/CVI/CVBS | |
General | Housing | Matal & Plastic |
Color | White | |
Operating Power | 12 VDC ± 25% | |
Consumption | Max. 2.9 W | |
Operating Temperature | -40 °F – 140 °F /-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP67 | |
Dimension (L x W x H) | 80 mm × Ø 85.1 mm (3.1" × Ø 3.4") | |
Weight | Approx. 300 g (0.66 lb.) |
