HIK OEM 8MP ColorVu Acusense IP Camera replace DS-2CD2387G2-LSU/SL Strobe Light Audible Warning 2-way Audio Surveillance Camera

8MP ColorVu Acusense IP Camera OEM HIK DS-2CD2387G2-LSU/SL Strobe Light and Audible Warning Two-way Audio CCTV Cameras

8 MP ColorVu Strobe Light and Audible Warning Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)

1.Camera
Image Sensor:1/1.2″ Progressive Scan CMOS
Max. Resolution:3840 × 2160
Min. Illumination:Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Speed:1/3 s to 1/100,000 s
Day & Night:24/7 Color imaging
Angle Adjustment:Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
2.Lens
Lens Type:Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV:
2.8 mm, horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124°
4 mm, horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°

Lens Mount:M mount
Iris Type:Fixed
Aperture:F1.0
Depth Of Field:2.8 mm: 4 m to ∞;4 mm: 6.2 m to ∞

3.DORI
DORI:
2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 9 m
4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m

4.Illuminator
Supplement Light Type:White Light
Supplement Light Range:Up to 30 m
Smart Supplement Light:Yes
5.Video
Main Stream
50 Hz:25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz:24 fps (3840 × 2160)'30 fps (3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)

60 Hz: 30 fps (640 × 480, 640 × 360)

Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

60 Hz: 10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)

Video Compression
Main stream: H.265/H.264/H.264+/H.265+

Sub-stream: H.265/H.264/MJPEG

Third stream: H.265/H.264

Video Bit Rate:32 Kbps to 16 Mbps
H.264 Type:Baseline Profile/Main Profile/High Profile
H.265 Type:Main Profile
Bit Rate Control:CBR/VBR
Scalable Video Coding (SVC):H.264 and H.265 encoding
Region Of Interest (ROI):1 fixed region for main stream and sub-stream
6.Audio
Environment Noise Filtering:-U: Yes
Audio Sampling Rate:-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
7.Network
Simultaneous Live View:Up to 6 channels
API:Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK , ISUP
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
User/Host:Up to 32 users. 3 user levels: administrator, operator and user
Security:Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage:NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client:iVMS-4200, Hik-Connect, Hik-Central
8.Web Browser
Plug-in required live view: IE 10, IE 11

Plug-in free live view : Chrome 57.0+, Firefox 52.0+

Local service: Chrome 57.0+, Firefox 52.0+

9.Image
Wide Dynamic Range (WDR):130 dB
SNR:≥ 52 dB
Privacy Mask:8 programmable polygon privacy masks, mask color or mosaic configurable
Day/Night Switch:Day, Night, Auto, Schedule
Image Enhancement:BLC, HLC, 3D DNR
Image Parameters Switch:Yes
Image Settings:Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
10.Interface
Ethernet Interface:1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB
Built-In Microphone:Yes
Built-In Speaker:1.5 W, 10 cm: 95 dB
11.Audio
1 input (line in), max. input amplitude: 3.3 Vpp, input impedance:4.7 KΩ, interface type: non-equilibrium

1 output (line out), max.output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Alarm:1 input, 1 output (max. 24 VDC, 1 A)
Reset Key:Yes
12.Event
Basic Event:Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)), scene change detection
Linkage:Upload to NAS/memory card/FTP, notify surveillance center, trigger record, trigger capture, send email
Deep Learning Function
Face Capture:Yes
13.General
Power:12 VDC ± 25%, 0.63 A, max. 8.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection

PoE: 802.3af, Class 3, 36 V to 57 V, 0.24 A to 0.15 A

Material:Cover: metal, main body: metal
Dimension:Ø138.3 mm × 120.1 mm (Ø5.4" × 4.7")
Package Dimension:170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9"),Approx. 900 g (2 lb.)
With Package Weight:Approx. 1190 g (2.6 lb.)
Storage Conditions:-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages:English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function:Anti-flicker, heartbeat, mirror, password reset via e-mail, pixel counter
14.Approval
EMC:FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN32: 2015, KN35: 2015)

Safety:UL (UL 62368-1),CB (IEC 62368-1: 2014+A11),CE-LVD (EN 62368-1: 2014/A11: 2017)

Environment:CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)

Protection: IP67: IEC 60529-2013

24/7 colorful imaging andhuman and vehicle targets classification

Active strobe light and audio alarm to warn intruders off

Two-way Audio Built-in Mic and Speaker

1. 8MP IPC*1(white or black)
2. Waterproof accessories *1
3. Screw*1lot
4. User guide *1
