Hikvison 4K AcuSense NVR DS-7608NXI-I2/8P/S 12MP 8CH POE H.265+ 2SATA CCTV Video Recordere For IP Camera Security System
| | | | |
| | | | |
Hikvision 4K AcuSense NVR DS-7608NXI-I2/8P/S 12MP 8MP 8CH POE H.265+ 2SATA CCTV Video Recordere For IP Camera Security System
1. This model is Hikvision original NVR , it support upgrade .
2. Our store support shipping from different warehouse , Products shipped from Spain / Russia / United States / Australia warehouse are Free Import Tax , from China are not free .
3. Please contact us if you can't find the models you need , we can order from Hikvision Factory for you ( MOQ>1000USD ) .
4. Please contact us if you are an installer or local agent
5.Face Picture LibraryUp to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)Face Picture Comparison4-ch face picture comparison alarm
Facial Detection And AnalyticsFace picture comparison, human face capture, face picture search ,Facial Detection And Analytics Performance1-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)
Hikvision 4K AcuSense NVR DS-7608NXI-I2/8P/S
8/16-ch 1U 8/16 POE AcuSense 4K NVR
> H.265+/H.265/H.264+/H.264 video formats
> Intelligent analytics based on deep learning algorithm
> Up to 4-ch perimeter protection
> Up to 1-ch facial recognition for video stream
> Up to 4-ch facial recognition for face picture
> Up to 8/16-ch IP camera inputs
> Up to 16-ch 1080p decoding capability
1.Facial Recognition | |
Face Picture Library | Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB) |
Face Picture Comparison | 4-ch face picture comparison alarm |
Facial Detection And Analytics | Face picture comparison, human face capture, face picture search |
Facial Detection And Analytics Performance | 1-ch human face capture (HD network camera, up to 8 MP, H.264/H.265) |
2.Perimeter Protection | |
Human/Vehicle Analysis | Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm |
3.Video And Audio | |
IP Video Input | 8/16 ch |
Incoming Bandwidth | 80/160 Mbps |
Outgoing Bandwidth | 256 Mbps |
HDMI Output | 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
VGA Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
Video Output Mode | HDMI/VGA independent output |
CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
4.Decoding | |
Decoding Format | H.265,H.265+,H.264,H.264+,MPEG4 |
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Playback Mode | Normal/Smart, Event, Tag, Eternal File |
Synchronous Playback | 8/16 ch |
Live View Window Division | 1/4/6/8/9/16 |
Aux Port Window Division | 1/4/6/8/9/16 |
Decoding Capability | 8/16 ch @ 1080p (30 fps) |
Audio Compression | G.711ulaw,G.711alaw,G.722,G.726,MP2L2 |
5.Network | |
Network Interface | 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
6.PoE | |
Interface | 8/16, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
Power | 8CH≤ 120W,16CH≤ 200W |
Standard | IEEE 802.3 af/at |
7.Auxiliary Interface | |
SATA | 2 SATA interfaces |
Capacity | Up to 8 TB capacity for each disk |
Serial Interface | RS-485 (half-duplex), RS-232, Keyboard |
Alarm In/Out | 4 in/1 out |
USB Interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
8.General | |
Power Supply | 8CH≤ 180W,16CH≤ 280W |
Consumption | ≤ 15W |
Working Temperature | -10℃～＋55℃ |
Working Humidity | 10％～90％ |
Chassis | 1U |
Dimension (W × D × H) | 385 × 315 ×52 mm ( 11.6"× 9.5" × 1.6"),≤ 3 kg (6.6 lb) |
4K 2K 1080Poptional
(multi-pixel optionalprovide clearly vision for you)
PCSmartphone Remote View
(You can monitor you care any place with internet)
Video Playback
(Playback History Video, recall happy time, share with your friend and provide more evidence to police Incident video clips can be found and marked in no time with smart playback function)
Maximum storage capacity up to 16TB
(2 SATA single supports up to 8TB, which can better record and replay the situation during the monitoring time to protect your property safety)
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
(H.265+technonlogy reduces bit rate and storage requirements by up to 70 when compare to standard H265 video compression)
NVR usage scenarios
(Suitable for various important places, easy to install and connect to the network camera)
1. 1x Hikvision Original NVR DS-7608NXI-I2/8P/S with original box .
2. 1x User manual .
3. 1x Mouse
4. 4x SATA cable
5. 1x Power adapter
6. 1x LAN cable
Question: Is this NVR original ?
Answer : This item is Original Hikvision DS-7600 Series 12MP 16POENVR,original firmware support upgrade.
Question: What's the model of this NVR ?
Answer : NVR DS-7608NXI-I2/8P/S
Question: What's the logo on the NVR and box ?
Answer : NVR comes with 'Hikvision' logo, Package box is original box from hikvision factory .
Question: Can I trust you ? there are many fake items on other stores !
Answer :100% Genuine Hikvision ! ALL EQUIPMENT FIRMWARE CAN BE UPGRADED AT ANYTIME
Question: I do business on hikvision products and I need more discount!
Answer :For bulk purchases and kit customize, please kindly contact us before buying .
