Original Hikvision DS-7608NI-K2-8P 8CH 8POE 4K NVR & DS-7616NI-K2-16P 16CH 16Port PoE 2SATA HDD Plug & Play Upgradeable
Original Hikvision DS-7608NI-K2-8P 8CH 4K NVR DS-7616NI-K2-16P 16CH 16Port PoE 2SATA HDD Plug & Play Upgradeable
DS-7608NI-K2/8P
Embedded Plug & Play 4K NVR
• Third-party network cameras supported
• Up to 8 Megapixels resolution recording
• Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160) resolution
• 8ch network cameras can be connected with 80M incoming bandwidth
• Up to 2 SATA interfaces
• Plug & Play with up to 8 independent PoE network interfaces
• Support dual-os to ensure high reliablility of system running
•Support various VCA detection alarm and VCA search
•Support H.265/H.264/MPEG4 video formats
DS-7608NI-K2/8P
Video/Audio Input | |
Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
IP video input: | 8-ch |
Network | |
Incoming bandwidth: | 80Mbps |
Outgoing bandwidth: | 160Mbps |
Video/Audio Output | |
HDMI Output: | 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
Recording Resolution: | 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
VGA Output: | 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
Decoding | |
Capability: | 8-ch@1080P |
Live view / Playback: | 8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Hard Disk | |
SATA: | 2 SATA interfaces for 2 HDDs |
Capacity: | Up to 6TB capacity for each HDD |
External Interface | |
USB Interface: | 2, USB2.0 |
Alarm In: | 4-ch |
Alarm Out: | 1-ch |
POE | |
Interface: | 8 independent 10 /100 Mbps PoE Ethernet interfaces |
General | |
Power Supply: | 100 to 200 VAC |
Consumption(without hard disk and POE): | ≤ 15 W |
Working Temperature: | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
Working Humidity: | 10 % ~ 90 % |
Chassis: | 385 mm chassis |
Dimensions: | 385 × 315× 52 mm (15.2" 12.4" 2.0") |
Weight(without HDD): | ≤ 3 kg (6.6 lb) |
PACK LIST :
