SANNCE 8CH 8MP Wired NVR POE Security Camera System 5MP IP66 Outdoor IR-CUT CCTV Canera Video Surveillance Video Recorder Kit
NVR | ||
Video & Audio | Video Compression | H.265+ |
IP Video Input | 8CH POE+2CH | |
Video Output | HDMI Up to 4K | |
Audio Output | Support | |
Max Recording Resolution | Up to 8M(3860x2160) | |
Max Playback Resolution | Up to 8M(3860x2160) | |
Max Playback Channel | 4CH | |
Max Playback Capacity | 4CH 3MP/2CH 5MP/1CH 8MP | |
Hard Drive | HDD | 1 SATA interface |
HDD Capacity | Up to 12TB capacity | |
| Network interface | RJ45x1(10/100/1000M) |
POE | 8 Ports(IEEE802.3at/af) | |
USB | USB2.0x2 | |
General | Housing | Metal for main part |
Operating Power | DC48V | |
Power Consumption | 10W(without HDD) | |
POE: Max 15W for single port | ||
Working Temperature | 32 °F – 131 °F /0 °C – 55 °C | |
Dimensions(W x H x D) | 10.2' x 9.6' x 1.9' / 260x245x47mm | |
Weight (without hard disk) | 1.68lbs / 760g(without HDD) | |
5MP IP Camera | ||
Camera | Video Resolution | 5MP(2880x1616) |
Image sensor | 1/2.8" Progressive Scan CMOS | |
Video compression | H.265+ | |
Audio Compression | G.711A | |
Lens | 3.6mm | |
Angle of View | 70° | |
Number of Infra-Red LEDs | 36 | |
Night Vision Distance | Up to 100ft/30m | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | YES | |
Ethernet | RJ45x1(10M/100M) | |
General | Housing | Metal |
Operating Power | DC12V;PoE (802.3af) | |
Operating Temperature | -4 °F – 140 °F /-20 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 6.7' x 2.6' x 2.6' / 170 x 65 x 65mm | |
Weight | 0.772lbs / 350g | |
8MP IP Camera | ||
Camera | Video Resolution | 8MP(3840×2160) |
Image sensor | 1/2.7" Progressive Scan CMOS | |
Video compression | H.265+ | |
Audio Compression | G.711A | |
Lens | 2.8mm | |
Angle of View | 105° | |
Number of Infra-Red LEDs | 36 | |
Night Vision Distance | Up to 100ft/30m | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | YES | |
Ethernet | RJ45x1(10M/100M) | |
Onvif | Support | |
General | Housing | Metal |
Operating Power | DC12V;PoE (802.3af) | |
Operating Temperature | -4 °F – 140 °F /-20 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 170 x 65 x 65mm | |
Weight | 350g | |
8CH NVR and 4pcs Cameras package Include:
1X DVR
4X Cameras
2X 30M Ethernet Cable
2X 18M Ethernet Cable
1X Power Adapter
1X USB Mouse
1X User's Manual
4X Mounting Screw Bags
8CH NVR and 6pcs Cameras package Include:
1X DVR
6X Cameras
3X 30M Ethernet Cable
3X 18M Ethernet Cable
1X Power Adapter
1X USB Mouse
1X User's Manual
6X Mounting Screw Bags
8CH NVR and 8pcs Cameras package Include:
1X DVR
8X Cameras
4X 30M Ethernet Cable
4X 18M Ethernet Cable
1X Power Adapter
1X USB Mouse
1X User's Manual
8X Mounting Screw Bags
